Bi-stable coupling relay for KNX Multi IO.

Application area

The Multi IO Extension Switch 590 serves as a power-saving alternative to commercial standard coupling relays.

The coupling relay is controlled as a mono-stable relay, but uses a bi-stable relay internally, thus reducing the holding current by up to 95%.

The Multi IO Extension Switch 590 has an integrated fuse to protect high-quality equipment.

5-channel, constant-voltage DALI-2 DT8 LED controller designed for versatile LED strip systems.

Supports:

• Built-in DALI-2 interface

• 12–36 V DC input

• 5 × 5 A outputs (240–720 W total)

• Multi-device modes: Tc, RGBWAF, XY, RGB+Tc

• The power supply of the electronics occurs via the connection to the primary line. This makes possible to detect and report a bus voltage failure at the secondary line.
• Used as a line coupler, it joins up the lines with the main line to create a function zone; as a backbone coupler, it joins up the function zones with the overriding backbone line.
• Both types of couplers link primary lines and secondary lines as governed by their filtering tables to only pass on group telegrams if their destination address is recorded in the filtering table.
• Used as a repeater the device enables the connection of more than 64 bus devices to one bus line.
• Up to three repeaters can be connected to one bus line (as shown in figure 1) thus enabling the connection of a total of 252 bus devices (additionally to the three repeaters) to one bus line.

• KNX/BACnet Gateway: Bridges communication between KNX and BACnet networks.
• 250 Communication Objects: Converts KNX group addresses into BACnet objects automatically.
• COV Subscriptions: Supports up to 455 real-time value subscriptions for efficient monitoring.
• Integrated Web Server: Offers a user-friendly interface for configuration and monitoring.
• Remote Parameterization: Includes a KNXnet/IP interface for remote access via ETS.
• Security Options: Features password protection and VPN support for secure network access.
• Flexible Power Supply: Operates with external SELV AC/DC 24V.
• DIN Rail Compatible: Easy to install on DIN rails for a compact setup.

The IP router has the following attributes:

• Easy to connect to higher-level systems by using the internet protocol (IP)
• Secure access and data transfer via KNXnet/IP Secure
• Direct access to the KNX installation from every point in the IP network (KNXnet/IP tunneling)
• Fast communication between KNX lines, areas and systems (KNXnet/IP routing)
• Communication across buildings and properties (networking properties)
• Filtering and forwarding of telegrams according to: Physical address, Group address
• LED displays for Operational readiness, KNX communication, IP communication
• Easy and secure configuration using ETS
• Easy to connect to visualization systems and facility management systems
• Slot for SD card (not in use)

IP Interface Secure has the following attributes:

•  Easy to connect to higher-level systems by using the internet protocol (IP)
• Direct access to the KNX installation from every point in the IP network (KNXnet/IP tunneling)
• Up to five KNXnet/IP tunneling connections are possible at the same time
• LED displays for operational readiness, KNX communication and IP communication
• Easy and secure configuration using ETS
• Easy to connect to visualization systems and facility management systems
• Slot for SD card (not in use)

• Secure KNX/IP Gateway: Enables communication between KNX systems and IP networks with KNX IP Secure encryption.
• Power Over Ethernet (PoE): Can be powered via PoE or an external 24V AC/DC supply.
• Remote Access: Provides secure remote access to KNX systems through VPN connections.
• Multiple Connections: Supports up to five simultaneous KNXnet/IP tunneling connections.
• LED Indicators: Features LEDs for KNX, IP communication, and power status.
• Easy Configuration: Configured through ETS software, supporting secure commissioning.
• Compact Design: Designed for DIN rail mounting, ideal for distribution boards.
• Flexible Power Options: Operates via PoE or separate power supply, ensuring flexibility in installation.

• Direct Mode Pushbutton: The button with an integrated yellow LED toggles between bus mode and direct mode.
• Brief Press Functionality: Pressing the button briefly activates the green LED for 30 seconds, indicating the last selected module (A to E) and the switching state of the outputs (red LEDs on buttons 1 to 3).
• Switching State Indication: The red LEDs in buttons 1 to 3 show the relay contact status: LED ON = contact closed, LED OFF = contact open.
• Activating Direct Mode: Holding the button for at least 3 seconds turns on the yellow LED, indicating that direct mode is now active.
• Output Control in Direct Mode: In direct mode, each output of the currently selected module can be switched on or off via a pushbutton on the top of the main module, using a toggle function.
• Pushbutton Behavior: Pressing the pushbutton once turns the output on if it's off, and pressing it again turns it off. The red LED on the pushbutton shows the current state.
• Unused Buttons: Pushbuttons 4 to 6 and their LEDs are not utilized in the N 513/11 model.
• Module Selection: To change the output state of a different module, the desired module must be selected by pressing the direct mode pushbutton multiple times.

• Device Type: The switching actuator sub-module N 513/21 is a DIN-rail mounted device in N-system dimensions.
• Relay Outputs: It can switch three groups of electrical consumers independently via its three relay contact outputs.
• Load Monitoring: Each relay output features load current measurement and monitoring (load-check).
• Standalone Operation: The sub-module cannot operate independently and must be connected to a main module.
• Connection Method: It connects via a 6-pole bridging connector to a main module (N 513/11, N 512/11, or N 562/11) or to another sub-module already connected to a main module.
• Power Supply: The sub-module’s electronics are powered by bus voltage through the 6-pole bridging connector.
• Modular Extension: Up to 4 sub-modules can be connected in series to a main module, extending it from 3-fold to 15-fold switching capability.

• The sunblind actuator N 523/04 only works together with the application program 25 A4 Venetian blind actuator 981201.
• The Engineering Tool Software (ETS) up from ETS2 V1.3 is required for the parameterisation and for loading the application program.
• This is structured so that there is sufficient basic functionality available in the supplied state for simple applications in combination with 11 basic communication ob-jects: the always available object "Status Direct mode", an alarm object that influences all channels, an object "Blockade" that also influences all channels and the two 1-bit command objects per channel enabling a blind to be moved into the upper or lower final position, to stop the drive and to open or close the slats stepwise.
• When commissioning the sunblind actuator the following objects can be added per channel, if needed, via the parameter tab "Functions, Objects":

• Manages up to 1,250 KNX statuses and values, with easy access via standard web browsers on PCs, tablets, and smartphones.
• Flexible Visualization: Offers graphical and mobile-friendly editors for customizable control and display elements, adaptable to various styles and devices.
• Advanced Automation: Includes timer, scene, and alarm modules, supporting up to 5,000 events and 250 alarms, ensuring robust automation and monitoring.
• IP Integration: Controls up to 20 IP devices and integrates seamlessly with SONOS speakers and Philips HUE lighting systems.
• Efficient Connectivity: Features a 10/100 Mbps Ethernet interface for reliable IP network connections, powered by an external 24V AC/DC source.
• KNX Network Control: Monitors and controls up to 1,250 KNX statuses and values.
• User-Friendly Access: Operates through standard web browsers on PCs, tablets, and smartphones.
• Graphical Customization: Includes web and smart editors for creating customizable visualizations.

External Temperature sensor (-20°C to +80°C) on 3m cable for NETIO devices with DI (Digital Input).

The USB-KNX interface OCI702 serves to provide a USB-KNX connection to access tools from a Microsoft Windows PC to a KNX network or individual device. It consists of the OCI702 service interface as well as several connection cables and accessories including cable ties and a service bag.

Simple and fast: The PUSH WIRE® plug-in terminal connection is the uncomplicated and fast way to connect a kink-resistant conductor.

The dimensions are (10 x 11.5 x 10) mm in width x height x depth.

The surface of the contacts is made of tin.

PowerCable 2KB is a smart 2x 120V/15A device with LAN connectivity and WiFi.

Each output can be switched ans metered individually. Web interface, HTTPs, NETIO Cloud, M2M protocols: XML http, JSON http and URL API. ZVS (Zero Voltage Switching).

PowerCable 2KZ is a smart 2x 230V/16A device with LAN connectivity and WiFi.

Each output can be switched and metered individually.

Web interface, HTTPs, NETIO Cloud, M2M protocols: XML http, JSON http and URL API. ZVS (Zero Voltage Switching).

No power cords included. Mounting with terminals

PowerCable 2PB is a smart 2x 120V/15A device with LAN connectivity and WiFi. Each output can be switched individually.

Web interface, HTTPs, NETIO Cloud, M2M protocols: XML http, JSON http and URL API. ZVS (Zero Voltage Switching).

PowerCable 2PZ is a smart 2x 230V/16A device with LAN connectivity and WiFi.

Each output can be switched individually.

Web interface, HTTPs, NETIO Cloud, M2M protocols: XML http, JSON http and URL API. ZVS

(Zero Voltage Switching).

No power cable included. Mounting with terminals

PowerDIN 4PZ is 2 channel electricity meter with relay output + 2x DI, 2x power relay, 110/230V max 16A in total.

LAN & WiFi connectivity, NFC for configuration, ZCS, IOC.

NETIO Cloud + Open APIs (SNMP, MQTT-flex, XML/JSON, Modbus/TCP & other protocols supported).
