Drivers and ECGs

Overview

• Communication interface between DALIsystems and the configuration software tool: DALI Cockpit.
• Bidirectional data communication for DALI bus monitoring, configuration and control.
• Support of the Standard DALI protocol, DALI-2 protocol, and various extended DALI protocols
• USB and DALI-line are galvanically isolated.
• Supply via DALI-line and USB interface
• Various types available: standard, mini, with integrated 30mA bus power supply, DALI-2 version with integrated 30mA bus power supply, for DIN rail mounting, for DIN rail mounting with flash memory, wireless
• 2 sets of DALI terminals for easy connection - signal line can be looped through

Overview

• Communication interface between DALIsystems and the configuration software tool: DALI Cockpit.
• Bidirectional data communication for DALI bus monitoring, configuration and control.
• Support of the Standard DALI protocol, DALI-2 protocol, and various extended DALI protocols
• USB and DALI-line are galvanically isolated.
• Supply via DALI-line and USB interface
• Various types available: standard, mini, with integrated 30mA bus power supply, DALI-2 version with integrated 30mA bus power supply, for DIN rail mounting, for DIN rail mounting with flash memory, wireless.
• 2 sets of DALI terminals for easy connection - signal line can be looped through

Overview

• Multimaster capable, multiple modules can be installed on the DALI-line
• The module is supplied directly by th DALI-line, no additional supply required
• Mmounting on cavity walls or conduit boxes
• Various cross plates available as accessory
• Application controller: freely assignable
• Function for each button for direct control of luminaires
• Factory settings provide common functions (switch and dim) without need of configuration
• Easy configuration via DALI USB and DALI Cockpit Software tool
• Individual addresses (0-63), group addresses (0-15) or broadcast can be used as effective range
• Different switching modes can be assigned to each pushbutton (short, long press; toggle; etc.)

Overview

• Control device for DALI-systems
• 4 standard layouts for colour and colour temperature control and Switching/Dimming
• Individual layout configuration (up from firmware 4.8)
• Configuration with DALI-Cockpit software tool and DALI-USB interface
• Multimaster capable - multiple touch panels can be installed on the same DALI-line.
• Frame material in plastic
• Customized frame colours and directly printed surface for OEM
• The DALI touch panel can be mounted on a conduit box.
• The module is supplied directly via the DALI signal line

• DALI Real Time Clock
• Time can be set and queried via DALI
• Scheduler Function – up to 28 entries
• Astro-clock function (up from firmware 2.4)
• For each scheduler job weekday mask, time stamp and a DALI command can be defined
• Easy schedule configuration via DALI Cockpit software tool and DALI USB interface
• Daylight saving mode
• The DALI RTC module must not be connected to the mains. It is supplied directly via the DALI signal line.
• Battery inside, as factory default the clock is set to local time (GMT+1)
• Simple installation due to DALI double-clamp connector
• Types for backbox installation and DIN rail mounting, suitable for installation in protection class II devices

Overview

• Control device for DALI DT8 uminaires (colour mode Tc)
• Ciorhythmic time-adjusted colour temperature (Tc) reference value
• DALI real time clock
• Daylight saving time (DST) Configurable scene behaviour (firmware 1.5+) Light level curve (firmware 2.0+)
• The time and the colour temperature characteristics over time can be configured with the help of the DALI Cockpit software tool
• The DALI CDC module is supplied directly via the DALI line, no additional power supply is required.
• A battery is included, the clock is set to local time (GMT+1) as factory default
• Simple installation due to DALI double-clamp connector
• Types for backbox installation and DIN rail mounting, suitable for installation in protection class II devices

Overview

• Control device for DALI DT8 uminaires (colour mode Tc)
• Ciorhythmic time-adjusted colour temperature (Tc) reference value
• DALI real time clock
• Daylight saving time (DST)
• Configurable scene behaviour (firmware 1.5+)
• Light level curve (firmware 2.0+)
• The time and the colour temperature characteristics over time can be configured with the help of the DALI Cockpit software tool
• The DALI CDC module is supplied directly via the DALI line, no additional power supply is required.
• A battery is included, the clock is set to local time (GMT+1) as factory default
• Simple installation due to DALI double-clamp connector
• Types for backbox installation and DIN rail mounting, suitable for installation in protection class II devices

Overview

• DALI-2 control module with 2 switching inputs for mains voltage
• Version with integrated DALI Bus power supply (50mA) – article number: 86458507-1L-PS
• Galvanic isolation between switching input and DALI-line
• Application controller: different DALI commands, destination addresses and switching modes can be assigned to each input.
• Multi-master capability, several modules can be installed on the same DALI-line.
• DALI DT8 support for adjustable white luminaires with the help of special macros

Overview

• DALI control module with 4 switching inputs for mains voltage
• Galvanic isolation between switching input and DALI-line
• Configurable function for each input
• Destination address, switching mode and DALI-commands can be assigned to each input
• DALI DT8 support for adjustable white luminaires with the help of special macros Adjustable „power up“-function
• The function of the switching input can be configured with the help of the DALI Cockpit and a DALI USB interface
• Multi-master capability, several modules can be installed on the same DALI-line
• Suitable for installation in protection class II devices or back box installation

Overview

• DALI control module with 4 switching inputs for mains voltage
• Galvanic isolation between switching input and DALI-line
• Configurable function for each input
• Destination address, switching mode and DALI-commands can be assigned to each input
• DALI DT8 support for adjustable white luminaires with the help of special macros
• Adjustable „power-up“-function
• The function of the switching input can be configured with the help of the DALI Cockpit and a DALI USB interface
• Multi-master capability, several modules can be installed on the same DALI-line
• Suitable for installation in protection class II devices or back box installation

Overview

• Small interface module for the conversion of 0-10V control signals to DALI dim levels
• Devices with 1, 2 and 3 channels available
• The 0-10V voltage is transformed to a a DALI dim level and DALI-command Off and sent to the defined effective range on the DALI line
• A change on the 0-10V input voltage (<1%) is used as event trigger
• Supply voltage 12V to 24V DC (e.g. 24V/300mA Art.Nr. 24166012-24HS), multiple devices can be supplied by the same supply voltage
• Configuration of effective range and conversion characteristic (conversion curve and behaviour below 1V input voltage) via DALI-Cockpit and DALIUSB-interface

Overview

• Small interface module for the conversion of 0-10V control signals to DALI dim levels
• Devices with 1, 2 and 3 channels available
• The 0-10V voltage is transformed to a a DALI dim level and DALI-command Off and sent to the defined effective range on the DALI line
• A change on the 0-10V input voltage (<1%) is used as event trigger
• Supply voltage 12V to 24V DC (e.g. 24V/300mA Art.Nr. 24166012-24HS), multiple devices can be supplied by the same supply voltage
• Configuration of effective range and conversion characteristic (conversion curve and behaviour below 1V input voltage) via DALI-Cockpit and DALIUSB-interface

Overview

• Module converting DALI dimming commands into PWM signal
• Easy integration of electronic ballast with PWM control input (e.g.Meanwell HLG, HLN, NPF or LPF series) in DALI lighting systems
• Advantage of fail-safe digital signal data communication compared to types with analog output voltage
• Transformation of DALI 8-Bit arc power level into PWM output signal (~500Hz) from 0% to 100%
• Selection of linear or logarithmic dimming curve (DT5)
• Output range selectable between 0-100% and 10-100% (DT5)

Overview

• The compact DALI relay module allows direct control of 230V AC loads via DALI and is available in DALI-2 certified variants (art. nr.: 86456944-_ and 86456203 -_).
• It enables integration of ballasts without DALI input into a DALI lighting control system, allowing loads to be switched ON and OFF by DALI commands.
• The DALI RM8/16 module meets the requirements for DALI Device Type 7 (switching function) with firmware 2.0 and higher.
• This module includes configurable Power-Up and System-Failure behavior and is supported by the free DALI-Cockpit software package for configuring DALI systems and Lunatone DALI components.
• The RM8/16 is powered directly by the DALI signal line and features zero-cross switching.
• The RM16-HS and RM16-DE variants (art. nr.: 86458629-HS, 86456203-HS, 86458629-DE, 86456203-DE) include an integrated current limiter, making them suitable for loads with high inrush current (>100A).
• The DALI RM8/16 module functions like any conventional DALI ballast, allowing it to be addressed and configured as needed.

Overview

• The compact DALI relay module allows direct control of 230V AC loads via DALI and is available in DALI-2 certified variants (art. nr.: 86456944-_ and 86456203 -_).
• It enables integration of ballasts without DALI input into a DALI lighting control system, allowing loads to be switched ON and OFF by DALI commands.
• The DALI RM8/16 module meets the requirements for DALI Device Type 7 (switching function) with firmware 2.0 and higher.
• This module includes configurable Power-Up and System-Failure behavior and is supported by the free DALI-Cockpit software package for configuring DALI systems and Lunatone DALI components.
• The RM8/16 is powered directly by the DALI signal line and features zero-cross switching.
• The RM16-HS and RM16-DE variants (art. nr.: 86458629-HS, 86456203-HS, 86458629-DE, 86456203-DE) include an integrated current limiter, making them suitable for loads with high inrush current (>100A).
• The DALI RM8/16 module functions like any conventional DALI ballast, allowing it to be addressed and configured as needed.

Overview

• 4 channel relay control
• For the control of switched ballast via DALI
• Suitable for circuit breakers and relays with coils-voltages of 12V to 48V DC
• 4 DALI adresses, one for each channel (Device Type 7)
• Configuration with DALI-Cockpit software tool and DALI USB-Interface
• 2 types of housing
• Maximum input current 8A
• Maximum output current of 2A per channel

Overview

• The DALI dimmer is designed for dimming 230V LED retrofit bulbs via DALI (Device Type 4 from firmware 3.0 onward).
• It is available in various types to support different loads: 3W to 25W (PD) for back box installation and 10W to 300W (PD300) for remote ceiling and DIN rail installations.
• The dimmer supports trailing edge phase cut for resistive and capacitive loads, leading edge phase cut for resistive and inductive loads, and is also available as a universal dimmer.
• It converts the DALI dim level into a phase cut controlled voltage, either trailing or leading edge.
• The minimum dim level can be set via DALI (MIN LEVEL), and an additional operating mode as a switch (DT7 compliant) is available from firmware 3.5 onward.
• The module functions as a DALI-line client, possessing its own DALI address.
•  It also features double DALI terminals, allowing the DALI signal line to be connected through.

Overview

• The DALI dimmer is designed for dimming 230V LED retrofit bulbs via DALI (Device Type 4 from firmware 3.0 onward).
• It is available in various types to support different loads: 3W to 25W (PD) for back box installation and 10W to 300W (PD300) for remote ceiling and DIN rail installations.
• The dimmer supports trailing edge phase cut for resistive and capacitive loads, leading edge phase cut for resistive and inductive loads, and is also available as a universal dimmer.
• It converts the DALI dim level into a phase cut controlled voltage, either trailing or leading edge.
• The minimum dim level can be set via DALI (MIN LEVEL), and an additional operating mode as a switch (DT7 compliant) is available from firmware 3.5 onward.
• The module functions as a DALI-line client, possessing its own DALI address.
• It also features double DALI terminals, allowing the DALI signal line to be connected through.

Overview

• The DALI dimmer is designed for dimming 230V LED retrofit bulbs via DALI (Device Type 4 from firmware 3.0 onward).
• It is available in various types to support different loads: 3W to 25W (PD) for back box installation and 10W to 300W (PD300) for remote ceiling and DIN rail installations.
• The dimmer supports trailing edge phase cut for resistive and capacitive loads, leading edge phase cut for resistive and inductive loads, and is also available as a universal dimmer.
• It converts the DALI dim level into a phase cut controlled voltage, either trailing or leading edge.
• The minimum dim level can be set via DALI (MIN LEVEL), and an additional operating mode as a switch (DT7 compliant) is available from firmware 3.5 onward.
• The module functions as a DALI-line client, possessing its own DALI address.
• It also features double DALI terminals, allowing the DALI signal line to be connected through.

Overview

• The 1-channel DALI LED Dimmer is designed for constant voltage LED modules with operating voltages from 12V to 48V.
• It supports Sw&Dim and SwitchDim2 modes, allowing light level control through 1 or 2 switch inputs without DALI.
• From firmware version 4.0 onward, the device can also be controlled directly by a motion sensor, enabling the "corridor function."
• The dimmer is compact, suitable for integration into luminaires or remote ceiling installations.
• It supports maximum input currents of 4A, 8A, 10A, or 16A, depending on the type.
• The dimmer features low standby power consumption, high efficiency, and is configured via PC software DALICockpit and a DALI USB interface.
• It also comes with user-friendly factory default settings.
