Drivers and ECGs

Overview

• The 4-channel DALI LED Dimmer is designed for constant current LED modules.
• It supports two operating modes: DT6 for individual channel control using 4 DALI addresses, and Colour&Dim, which uses 2 DALI addresses—one for light level adjustment and one for color adjustment.
• Additionally, SwitchDim2 mode allows control of light level and color with 2 switch inputs, bypassing DALI.
• The dimmer offers a dimming range from 0.1% to 100% and comes in versions with a common plus connector for currents up to 500mA or a common minus connector (GM) for currents up to 700mA.
• It is an independent control gear suitable for integrating into luminaires (Class II) and for remote ceiling installations.
• The device operates with a supply voltage of 12V to 48V DC and provides an output voltage of up to 45V DC.

Overview

• The 4-channel DALI LED Dimmer is designed for constant current LED modules.
• It supports two operating modes: DT6 for individual channel control using 4 DALI addresses, and Colour&Dim, which uses 2 DALI addresses—one for light level adjustment and one for color adjustment.
• Additionally, SwitchDim2 mode allows control of light level and color with 2 switch inputs, bypassing DALI.
• The dimmer offers a dimming range from 0.1% to 100% and comes in versions with a common plus connector for currents up to 500mA or a common minus connector (GM) for currents up to 700mA.
• It is an independent control gear suitable for integrating into luminaires (Class II) and for remote ceiling installations.
• The device operates with a supply voltage of 12V to 48V DC and provides an output voltage of up to 45V DC.

Overview

• The 4-channel DALI LED Dimmer is designed for constant current LED modules.
•  It supports two operating modes: DT6 for individual channel control using 4 DALI addresses, and Colour&Dim, which uses 2 DALI addresses—one for light level adjustment and one for color adjustment.
•  Additionally, SwitchDim2 mode allows control of light level and color with 2 switch inputs, bypassing DALI.
• The dimmer offers a dimming range from 0.1% to 100% and comes in versions with a common plus connector for currents up to 500mA or a common minus connector (GM) for currents up to 700mA.
• It is an independent control gear suitable for integrating into luminaires (Class II) and for remote ceiling installations.
• The device operates with a supply voltage of 12V to 48V DC and provides an output voltage of up to 45V DC.
• This flexibility makes it a versatile choice for various lighting applications, ensuring effective control and integration in different setups.

Overview

• The 4-channel DALI LED Dimmer is designed for constant current LED modules.
• It offers two operating modes: DT6 for individual channel control using 4 DALI addresses, and Colour&Dim, which uses 2 DALI addresses—one for adjusting light levels and one for color.
• In SwitchDim2 mode, it provides light and color control through 2 switch inputs without DALI.
• It comes in versions with either a common plus connector supporting up to 500mA or a common minus connector (GM) supporting up to 700mA.
• It is an independent control gear suitable for integration into luminaires (Class II) and remote ceiling applications.
• The supply voltage ranges from 12V to 48V DC, with an output voltage up to 45V DC.
• The dimmer includes short circuit protection, low standby power consumption, and high efficiency. Configuration is done via DALICockpit PC software and a DALI interface (e.g., DALI USB).

Overview

• 4-channel DALI LED Dimmer for constant current LED modules.
• Operating Modes:
• DT6: 4 DALI addresses for channel control.
• Colour&Dim: 2 DALI addresses for light and color.
• SwitchDim2: Control without DALI using 2 switch inputs.
• Dimming: 0.1% to 100% range.
• PWM Frequency: 122Hz to 1kHz options.
• Connectors: Common plus (up to 500mA) and minus (GM) (up to 700mA).
• Power: 12V-48V DC input, up to 45VDC output.
• Features: Short circuit protection, low standby power, high efficiency.
• Configuration: DALICockpit software and DALI interface.
• User-friendly default settings.

Overview

• 4 channel DALI LED-Dimmer
• Suitable for constant current LEDmodules
• Operating Mode DT6: individual channel control via 4 DALI addresses
• Operating Mode Colour&Dim: control by 2 DALI-addresses, one for adjusting the light level and one for adjusting the colour
• SwitchDim2: 2 switch-inputs offer control of light level and colour without DALI.
• Dimming range 0.1%-100%
• Adjustable PWM-frequency (122Hz/244Hz/488Hz/976Hz from FW version 4.6 on changed PWM frequencies: 250Hz / 500Hz / 1kHz)
• Types with common plus connector with constant currents up to 500mA

Overview

• 4 channel DALI LED-Dimmer
• Suitable for constant current LEDmodules
• Operating Mode DT6: individual channel control via 4 DALI addresses
• Operating Mode Colour&Dim: control by 2 DALI-addresses, one for adjusting the light level and one for adjusting the colour
• SwitchDim2: 2 switch-inputs offer control of light level and colour without DALI.
• Dimming range 0.1%-100%
• Types with common minus connector (GM) with constant currents up to 700mA
• Independent control gear, suitable for integration in luminaires (protection class II) and remote ceiling
• Supply voltage 12V to 48V DC
• Output voltage up to 45VDC
• Short circuit protection
• Low standby power consumption
• High efficiency

Overview

• DALI LED-Dimmer for the control of tunable white luminaires
• Suitable for constant voltage LEDmodules with operating voltages from 12V to 48V
• Operating Mode DT8: One DALIaddress for the independent control of light level and colour temperature (DALI DT8, Colour Type Tc)
• Operating Mode Balance&Dim: Control by 2 DALI-addresses, one for adjusting the light level and one for adjusting the channel balance (e.g. colour temperature)
• Operating Mode Dim2Warm: one DALI-address for simultaneous adjustment of light level and colour temperature
• SwitchDim2: 2 switch-inputs offer control of level and colour without DALI
• Dimming range 0.1%-100%
• Type dependent max. input currents of 4A, 8A, 10A or 16A
• The maximum input current can be freely distributed between the channels
• Low standby power consumption
• High efficiency
• Configuration via PC-software DALICockpit and DALI USB-interface
• User-friendly factory default settings

Overview

• Device with 2 DALI Tunable White LED-Dimmer
• For constant voltage LED modules (12V-48V)
• 2 DALI addresses (Device Type 8, Colour Type Tc)
• Independent control of light level and color temperature
• Dimming range: 1%-100%, PWM frequency: 488Hz DIN rail mounting compatible.
• Supply voltage: 12V-48V DC, Input current: 0.1A-16A
• Low standby losses, High efficiency >98%
• Configuration via DALI-Cockpit software and DALI USB interface

Overview

• DALI LED-Dimmer for RGB colour control suitable for constant voltage LEDmodules with operating voltages from 12V to 48V
• Operating Mode DT8: one DALIaddress for the independent control of light level and colour (DALI DT8, Type RGBWAF)
• Operating Mode Colour&Dim: control by 2 DALI-addresses, one for adjusting the light level and one for adjusting the colour
• supply voltage 12V to 48V DC (according to the operating voltage of the led modules)
• Type dependent max. input currents of 4A, 8A, 10A or 16A
• The maximum input current can be freely distributed between the channels.

• DALI LED-Dimmer for RGBW color control
• Suitable for constant current LEDmodules
• Operating Mode DT8: one DALIaddress for the independent control of level and color (DALI DT8, Type RGBWAF)
• Operating Mode Color&Dim
• SwitchDim2
• Dimming range 0.1%-100%
• Adjustable PWM-frequency (122Hz/244Hz/488Hz/976Hz from FW version 4.6 on changed PWM frequencies: 250Hz / 500Hz / 1kHz).
• Types with common plus and minus connector for constant currents up to 700mA.
• Independent electrical device, suitable for integration in luminaires (protection class II) or remote ceiling.
• Supply voltage 12V to 48V DC.
• Output voltage up to 45VDC.
• High efficiency.
• Configuration via PC-software DALICockpit and DALI interface (e.g. DALI USB).
