• DALI LED-Dimmer for the control of tunable white luminaires
• Suitable for constant voltage LEDmodules with operating voltages from 12V to 48V
• Operating Mode DT8: One DALIaddress for the independent control of light level and colour temperature (DALI DT8, Colour Type Tc)
• Operating Mode Balance&Dim: Control by 2 DALI-addresses, one for adjusting the light level and one for adjusting the channel balance (e.g. colour temperature)
• Operating Mode Dim2Warm: one DALI-address for simultaneous adjustment of light level and colour temperature
• SwitchDim2: 2 switch-inputs offer control of level and colour without DALI
• Dimming range 0.1%-100%
• Type dependent max. input currents of 4A, 8A, 10A or 16A
• The maximum input current can be freely distributed between the channels
• Low standby power consumption
• High efficiency
• Configuration via PC-software DALICockpit and DALI USB-interface
• User-friendly factory default settings

Overview

• Device with 2 DALI Tunable White LED-Dimmer
• For constant voltage LED modules (12V-48V)
• 2 DALI addresses (Device Type 8, Colour Type Tc)
• Independent control of light level and color temperature
• Dimming range: 1%-100%, PWM frequency: 488Hz DIN rail mounting compatible.
• Supply voltage: 12V-48V DC, Input current: 0.1A-16A
• Low standby losses, High efficiency >98%
• Configuration via DALI-Cockpit software and DALI USB interface

Overview

• DALI LED-Dimmer for RGB colour control suitable for constant voltage LEDmodules with operating voltages from 12V to 48V
• Operating Mode DT8: one DALIaddress for the independent control of light level and colour (DALI DT8, Type RGBWAF)
• Operating Mode Colour&Dim: control by 2 DALI-addresses, one for adjusting the light level and one for adjusting the colour
• supply voltage 12V to 48V DC (according to the operating voltage of the led modules)
• Type dependent max. input currents of 4A, 8A, 10A or 16A
• The maximum input current can be freely distributed between the channels.

• DALI LED-Dimmer for RGBW color control
• Suitable for constant current LEDmodules
• Operating Mode DT8: one DALIaddress for the independent control of level and color (DALI DT8, Type RGBWAF)
• Operating Mode Color&Dim
• SwitchDim2
• Dimming range 0.1%-100%
• Adjustable PWM-frequency (122Hz/244Hz/488Hz/976Hz from FW version 4.6 on changed PWM frequencies: 250Hz / 500Hz / 1kHz).
• Types with common plus and minus connector for constant currents up to 700mA.
• Independent electrical device, suitable for integration in luminaires (protection class II) or remote ceiling.
• Supply voltage 12V to 48V DC.
• Output voltage up to 45VDC.
• High efficiency.
• Configuration via PC-software DALICockpit and DALI interface (e.g. DALI USB).
