Shelly Wave 1PM

Mesh network - devices can communicate with each other in addition to the gateway. Devices (only mains powered) can act as repeaters to extend network.

Long range network - devices can communicate only with gateway (no repeater function).

S button - The Z-Wave® Service button, located on Z-Wave® devices and is used for various functions such as adding (inclusion), removing (exclusion), resetting the device to its factory default settings and to switch power output on/off (valid only for Wave Plugs).

The term "S button" is used in this document.

Device - In this document, the term “Device” is used to refer to the Shelly Wave device that is a subject of this guide.

End device - Z-Wave end devices are nodes in a Z-Wave network that are not gateways, such as switches, door locks, sensors, etc.

Node ID - The Z-Wave Node ID is a unique identifier assigned at the adding (inclusion) to each device in a Z-Wave network, allowing the network to identify and communicate with this device.

HOME ID - The Z-Wave Home ID is a unique identifier assigned to each Z-Wave network and each device in that network.

It distinguishes your Z-Wave network from other networks and ensures that your Z-Wave devices only communicate with devices in your own network.

Adding/Inclusion - The process of adding Z-Wave device to a Z-Wave network - gateway. The words included, added, etc. are used in this regard.

Removing/Exclusion - The process of removing Z-Wave device from a Z-Wave network - gateway.

The words excluded, removed, etc. are used in this regard.

Factory reset - After Factory reset, all custom parameters and stored values (kWh, associations, routings, etc.) will return to their default state.

The HOME ID and NODE ID assigned to the Device will be deleted.

Use this reset procedure only when the gateway is missing or otherwise inoperable.

Normal mode - Is the state of the device which refers to the operational state of a device when it is functioning under regular conditions (switching on/off, dimming, etc.) either during active usage or while in standby mode but still powered.

SmartStart - SmartStart enabled devices can be added (included) to a Z-Wave network by scanning the Z-Wave QR code on the device with a Gateway that supports SmartStart inclusion.

The SmartStart enabled device will be automatically added within 10 minutes of being switched on in the vicinity of the Z-Wave network.

MUST - MUST be implemented

OPTIONAL - implement it if time/budget allows

Associations - Associations are used for direct communication between the Device and other devices within your Z-Wave network without the need of the Z-Wave gateway.

Power cycle - Reboot the Device/power supply On/Off of the Device

Blind - Refers to any kind of window treatment, such as venetian blinds, roller blinds (screens), roller shutters, vertical window blinds, curtains, integral venetian blinds, pleated blinds, awnings, etc.

Additionally, Wave Shutter can also control window motors, projector screens, or any type of bi-directional AC motor.

Power consumption (W) - refers to the rate at which energy is consumed or used by an electrical device or system.

It is measured in watts (W).

Energy consumption (kWh) - refers to the total amount of electrical energy consumed by a device or system over a specific period of time.

It is measured in kilowatt-hours (kWh).

Ordering code - The ordering code is the same as the Part number (PN).

Where there is not enough space to write the Ordering code, abbreviation PN is used. The PN is written on the DSK label on each device.
