The Eelectron TS01D01ACC-3 is the 9025-series wall temperature probe in black for a 2-module flush box. It is a passive NTC sensor in the same glass-fronted format as the 9025 capacitive thermostats, so a bedroom, bathroom or second zone gets a design-matched temperature pick-up wired to the analog NTC input of any Eelectron KNX device — no extra bus device needed.
It is used with the 2-module glass cover (9025GS00A03 for this finish; 9025GS00A01 for the other) over up to 30 m (98 ft) of twisted cable; the element measures −5…+45 °C (23…113 °F). The white version is TS01D01ACC-1.
Key Features
- 9025-series wall temperature probe for a 2-module box, matching the 9025 capacitive thermostat look
- NTC element, measuring range −5…+45 °C (23…113 °F), tolerance ±2 %
- Connects to the analog NTC input of Eelectron KNX devices; max. 30 m (98 ft) twisted cable; keep ≥ 6 mm from live conductors
- Used with glass cover 9025GS00A03 (ordered separately)
- PC-ABS body, IP20; indoor, dry places; approx. 100 g (190 g with glass)
- Finish: black
Technical Specifications
| Type | Wall temperature probe, 9025 series, 2-module |
| Sensor | NTC, −5…+45 °C (23…113 °F), tolerance ±2 % |
| Connection | Rear input of the connected device; max. 30 m (98 ft) twisted cable |
| Compatible hardware | Eelectron KNX devices with analog NTC input (e.g. RT07A01KNX, RH07A01KNX, PD00E0x/E1x/E2x/E3x, TC28A01KNX, AD84C01KNX, IO04F01KNX) |
| Glass cover | 9025GS00A03 |
| Enclosure / protection | PC-ABS; IP20 (EN 60529) |
| Operating temperature | −5…+45 °C; storage −20…+55 °C; max. 90 % RH non-condensing |
| Dimensions | 96 × 96 × 36 mm (3.8 × 3.8 × 1.4 in) |
| Weight | 0.1 kg (0.22 lb) (datasheet: approx. 100 g, 190 g with glass) |
| Finish | Black |
| Manufacturer part no. / GTIN | TS01D01ACC-3 / 8054144522050 |
Related Products
TS01D01ACC-1 (white). Glass covers: 9025GS00A01 (white), 9025GS00A03 (black). 3-module version: TS01D01ACC-1-3M / TS01D01ACC-3-3M. Other probes: TS01A04ACC (−20…+100 °C, pack of 4), TS01B04ACC (−50…+60 °C, pack of 4), TS01C01ACC (metal case, −40…+105 °C). Thermostats of the same design: RT07A01KNX-1 / -3, RH07A01KNX-1 / -3.
Passive accessory – no electrical rating. The Eelectron KNX device it mounts on is CE certified; not UL/NRTL listed — verify local code requirements before specifying in US installations.
Datasheet (PDF) · Available to order.
