Eelectron PD54E09KNX-3 KNX High Bay Presence Detector IP54, Lighting Control – Black
✗
UL Listed
This product has not been certified by an NRTL (UL, ETL, CSA or
equivalent). Installation in USA projects may require a Field Evaluation
by a recognized laboratory. Consult your local AHJ before specifying.
~
Low Voltage · SELV
This device operates on a Safety Extra Low Voltage circuit — such as
the KNX 29V bus or a DALI 16V bus (NEC Class 2). When powered by an
NRTL-listed power supply, many AHJs accept non-listed SELV devices.
Verify with your local AHJ before specifying.
Regular price
$168.90 USD
Regular price
-26%
$229.60 USD
Sale price
$168.90 USD
Couldn't load pickup availability
KNX & DALI Specialists
Not sure which device fits your project? Our team speaks KNX. Contact us for a free technical recommendation.
Free shipping over $500
KNX certified devices
Expert technical support
Got questions?
Feel free to get in touch
Ask an expert!
The Eelectron PD54E09KNX-3 is the IP54 High Bay version of Eelectron’s KNX presence detector range in black, built for ceilings up to 16 m (52 ft) in warehouses, logistics halls, gyms, sports halls, atriums, workshops and covered loading areas — including the damp or dusty spaces where the standard IP20 High Bay (PD00E09KNX) cannot be used. It pairs PIR presence detection with an integrated illuminance sensor so high-bay LED luminaires are switched or dimmed by occupancy and daylight directly from the KNX bus.
Presence detection offers 5 independently configurable channels (presence with or without lighting control, automatic or semi-automatic). A rear connector carries 3 digital inputs for dry-contact pushbuttons or switches, one of which can be set as an analog NTC probe input for the built-in 2-stage PI thermostat. Twelve logic blocks, Circadian Rhythm tunable-white curves and the Virtual Holder occupancy logic are included. The white version is PD54E09KNX; the matching mounting accessory is PD54E00ACC-3.
Key Features
- IP54 High Bay PIR presence detector for ceiling mounting up to 16 m (52 ft)
- 5 independently configurable presence channels: presence with/without lighting control, automatic or semi-automatic detection
- Integrated illuminance sensor for ambient lighting control
- 3 rear digital inputs for dry-contact pushbuttons or switches: on/off, dimming, shutters/blinds, scenes, sequences, step commands
- One input configurable as analog for Eelectron NTC probes (TS00A01ACC / TS00B01ACC) — temperature to bus or full thermostat module
- Integrated 2-stage thermostat with PI controller for heating/cooling equipment, valves, 2- and 4-pipe fan coils
- 12 logic blocks with logical, threshold, algebraic and conditional operators; predefined proportional temperature/humidity and dew-point algorithms
- Circadian Rhythm lighting logic (predefined curves or real sun position); Virtual Holder occupancy logic for hospitality
- Dedicated IP54 mounting accessory PD54E00ACC-3
- Finish: black
Technical Specifications
| Bus | KNX TP (bus-powered) |
| Sensors | PIR presence detection (high-bay lens); illuminance sensor |
| Mounting height | Ceiling, up to 16 m (52 ft) |
| Presence channels | 5, independently configurable |
| Inputs – digital mode | 3 inputs for dry (potential-free) contacts on rear connector |
| Input – analog mode | 1 of the 3 inputs for NTC probe TS00A01ACC / TS00B01ACC |
| Thermostat | 2-stage with integrated PI controller |
| Logic blocks | 12 |
| Degree of protection | IP54 |
| Mounting accessory | PD54E00ACC-3 |
| Finish | Black |
| ETS application | Eelectron application program (download from eelectron.com) |
| Manufacturer part no. | PD54E09KNX-3 |
Related Products
PD54E09KNX (same detector in white). Mounting accessory: PD54E00ACC (white) / PD54E00ACC-3 (black). IP20 High Bay ceiling version: PD00E09KNX / PD00E09KNX-3; wall-mounted Hi-Bay up to 16 m: PD00E39KNX / PD00E39KNX-3; Standard 4 m ceiling detector: PD00E01KNX / PD00E01KNX-3. Outdoor PIR for parking areas: PD00F01KNX. Probes: TS00A01ACC, TS00B01ACC.
CE certified; not UL/NRTL listed — verify local code requirements before specifying in US installations.
