Eelectron MO04A01KNX-3 KNX Multi-Sensor 4-fold – black

The Eelectron MO04A01KNX-3 is the OL-U KNX multisensor in black, a wall-mounted room controller for 2- or 3-module flush boxes that combines temperature, humidity and CO2 sensing, two independent 2-stage thermostats, four mechanical pushbuttons and a backlit LCD in one 71 × 71 mm device. It is designed for the guest room, executive office or apartment living area where the client wants one elegant wall point for climate, air quality and lighting rather than a thermostat plus keypad plus sensor.

The two thermostats each run a PI controller for heating, cooling, valves, 6-way valves and 2-/4-pipe fan coils, so a bedroom and bathroom (or office and meeting area) can be controlled from one device; the humidity channel manages humidifiers and dehumidifiers with hysteresis thresholds; and the CO2 reading (400–2000 ppm) drives demand-controlled ventilation. A capacitive swipe bar under the display handles scenes and slow-swipe dimming or set-point changes, an RGB LED bar and one RGB LED per button show status, and 32 logic blocks plus the Virtual Holder hospitality logic are built into the Data Secure ETS application. Button kits and frames in plastic, metal or FENIX are ordered separately; the black finish takes the BKM4PLL-3 key set. Other finishes: MO04A01KNX-1 (white), MO04A01KNX-4 (Helvetia white).

Key Features

• Integrated temperature (−5…+55 °C), relative-humidity (0–100 %RH) and CO2 (400–2000 ppm) sensors
• Two independent 2-stage thermostats with PI controllers for heating/cooling, valves, 6-way valves, 2- and 4-pipe fan coils
• Humidity control with thresholds and hysteresis for humidification / dehumidification equipment
• 4 mechanical buttons (4 channels) for on/off, dimming, shutters/blinds and other programmable functions, each with an RGB LED
• Multifunction capacitive swipe bar: quick swipes for scenes, slow swipes for dimming / set-point / colour, single tap, double tap, long press
• Freely configurable RGB LED bar for status or any KNX bus value; LCD display with adjustable backlight and ECO mode
• 32 logic blocks with logical, threshold, algebraic and conditional operators; predefined proportional and dew-point algorithms
• Virtual Holder logic for accurate hotel-room occupancy from door contact + presence sensors
• KNX Data Secure; KNX interface integrated; 600 group addresses / 700 associations
• Fits 2- or 3-module boxes (Italian 502/503, German, British, Swiss standards); bus terminal and fixing screws supplied
• Finish: black; button kits in painted plastic, metal or FENIX ordered separately

Technical Specifications

Related Products

Other finishes: MO04A01KNX-1 (white), MO04A01KNX-4 (Helvetia white). Button kit for this finish: BKM4PLL-3 (BKM4PLL-1 white, BKM4PLL-3 black, BKM4PLL-4 Helvetia white; BKM4PL0-1 / -3 alternatives). Mounting frames FO71A01-2M (2-module) / FO71A01-3M (3-module); cover plates PO71A01RP-1 / -3 (2-module), PO71A03RP-1 / -3 (3-module), PO71A01PL-4 and PO71S01PL-1 / -3 / -4; SFBOA25-1 / -3 / -4 accessory. LITE version without swipe bar: MO04L02KNX-1 / MO04L02KNX-3. Thermostat-only LITE: TO04L02KNX-1 / -3.

CE certified; not UL/NRTL listed — verify local code requirements before specifying in US installations.
