Eelectron LM00B01KNX KNX monitoring module standard

SKU: LM00B01KNX
(0)
✗ UL Listed
This product has not been certified by an NRTL (UL, ETL, CSA or equivalent). Installation in USA projects may require a Field Evaluation by a recognized laboratory. Consult your local AHJ before specifying.
~ Low Voltage · SELV
This device operates on a Safety Extra Low Voltage circuit — such as the KNX 29V bus or a DALI 16V bus (NEC Class 2). When powered by an NRTL-listed power supply, many AHJs accept non-listed SELV devices. Verify with your local AHJ before specifying.
$177.90 USD
-26% $241.92 USD $177.90 USD
In stock
On backorder
KNX & DALI Specialists

Not sure which device fits your project? Our team speaks KNX. Contact us for a free technical recommendation.

Free shipping over $500
KNX certified devices
Expert technical support

Got questions?

Feel free to get in touch

Ask an expert!

Video chat Chat Email +1 (786) 956-6821

The Eelectron LM00B01KNX is a KNX line surveillance module: it polls up to 256 devices on the bus and reports each one as On line, Alarm or Warning, so a facility team learns about a failed actuator or a disconnected room controller before guests or tenants do. Two modules can be configured as primary and secondary for redundancy, and 16 logic blocks allow the alarm picture to be consolidated for a BMS or a visualization.

The 1-module device is bus-powered (under 5 mA), has a traffic/alarm LED and a reset button, and offers 1056 group addresses and 1232 associations to cover the monitored objects. It is a low-cost addition to hotel and office installations where availability matters.

Each monitored device is entered in ETS with its physical address and a polling interval; a missed response raises Warning, a sustained absence raises Alarm, and both states are available as group objects for a visualization, an e-mail gateway or a BMS. The logic blocks can group alarms by floor or by function, and the primary/secondary pairing keeps surveillance running even if one module is swapped or reprogrammed. The module adds negligible bus load and no additional power requirement to the line.

Key Features

  • Monitors up to 256 KNX devices (surveillance blocks) with On line / Alarm / Warning states
  • Primary/secondary redundancy between two modules
  • 16 logic blocks for alarm consolidation
  • Traffic / alarm LED and reset button
  • 1056 group addresses / 1232 associations
  • Bus-powered, ≤ 5 mA; 1-module PC-GF DIN housing, approx. 40 g

Technical Specifications

Power supply Via KNX bus, 21–32 V DC (SELV)
Current consumption ≤ 5 mA
Surveillance blocks 256
Logic blocks 16
Group addresses / associations 1056 / 1232
Controls Reset button; traffic/alarm LED; KNX programming button and LED
Mounting DIN rail, 1 module (18 mm / 0.71 in)
Enclosure PC-GF, IP20 (EN 60529)
Operating temperature -5 °C to +45 °C (23 °F to 113 °F)
Storage temperature -20 °C to +55 °C (-4 °F to 131 °F)
Relative humidity max 90 % non-condensing, indoor use
Standards EN 63044-3; EN 63044-5-1 / EN 63044-5-2; EN 50491-2; LVD 2014/35/EU; EMC 2014/30/EU
Certifications KNX certified; CE
ETS application LM00B01KNX surveillance module
Weight (net) 0.11 kg (0.24 lb)
Manufacturer part no. / GTIN LM00B01KNX / 8054144522265

Related Products

Device monitoring is also built into IPSBA01KNX / IPSBA02KNX / IPSBA03KNX (OnLine-OffLine for 128 devices). Couplers and interfaces: LC00S01KNX, IN00S01RIP, IN00S01IPI.

CE certified; not UL/NRTL listed — verify local code requirements before specifying in US installations.

Datasheet (PDF) · Available to order.
