Eelectron CV00A01KNX KNX Bus Cable 1X2X0,8 - 100 Mt

SKU: CV00A01KNX
(0)
✗ UL Listed
This product has not been certified by an NRTL (UL, ETL, CSA or equivalent). Installation in USA projects may require a Field Evaluation by a recognized laboratory. Consult your local AHJ before specifying.
~ Low Voltage · SELV
This device operates on a Safety Extra Low Voltage circuit — such as the KNX 29V bus or a DALI 16V bus (NEC Class 2). When powered by an NRTL-listed power supply, many AHJs accept non-listed SELV devices. Verify with your local AHJ before specifying.
$171.90 USD
-8% $187.04 USD $171.90 USD
In stock
On backorder
KNX & DALI Specialists

Not sure which device fits your project? Our team speaks KNX. Contact us for a free technical recommendation.

Free shipping over $500
KNX certified devices
Expert technical support

Got questions?

Feel free to get in touch

Ask an expert!

Video chat Chat Email +1 (786) 956-6821

The Eelectron CV00A01KNX is a 100 m (328 ft) coil of 1×2×0.8 mm KNX bus cable — a single red/black twisted pair for the KNX TP bus in the netbus-series construction for fixed indoor installation in conduit and under plaster. It is the lighter option where no auxiliary pair is needed: line runs between boards, risers, or the drop to each detector and keypad.

Solid 0.8 mm (20 AWG) copper, PE insulation, foil shield with drain wire and an LSZH sheath in KNX green (RAL 6018) meet EN 50090; CPR Eca class, flame retardant, and permitted alongside 450/750 V and 0.6/1 kV power cables (Uo ≤ 400 V). For a spare auxiliary pair choose CV00A02KNX.

Key Features

  • 1 × 2 × 0.8 mm (20 AWG) solid copper, one red/black bus pair
  • 100 m (328 ft) coil; approx. 3.5 kg
  • LSZH outer sheath in KNX green RAL 6018; PE core insulation
  • Foil shield with continuity (drain) conductor
  • netbus-series fieldbus cable for EIB/KNX, EN 50090 / EN 50090-2-2 reference
  • CPR class Eca (EU 305/2011); flame retardant per EN 60332-1
  • Permitted to coexist with 450/750 V and 0.6/1 kV power cables (Uo up to 400 V)
  • For fixed installation in ducts, conduit and under plaster

Technical Specifications

Construction 1 × 2 × 0.8 mm, one twisted pair red + black
Conductor Solid copper 0.80 mm (20 AWG)
Insulation / sheath PE cores; LSZH outer sheath, green RAL 6018
Shield Foil shield with continuity conductor
Fire performance CPR Eca (EU 305/2011); flame retardant EN 60332-1
Installation Fixed indoor installation in conduit / under plaster; may run with 450/750 V and 0.6/1 kV power cables (Uo ≤ 400 V)
Standards EN 50090, EN 50090-2-2, EN 50575:2014+A1:2016, EN 60332-1-2
Length / packaging 100 m (328 ft) coil
Weight 3.5 kg (7.72 lb)
Manufacturer part no. / GTIN CV00A01KNX / 8054144521053

Related Products

Two-pair 2×2×0.8 version with auxiliary pair: CV00A02KNX (100 m). 500 m reels: CV05A01KNX, CV05A02KNX. KNX bus connectors WG00A01ACC (red/black, 100 pcs).

CE / CPR (Eca) compliant cable; not UL listed — verify NEC Class 2 wiring and local code requirements before specifying in US installations.
