DALI RM16 0-10V – Converter with 16A Relay
✗
UL Listed
This product has not been certified by an NRTL (UL, ETL, CSA or
equivalent). Installation in USA projects may require a Field Evaluation
by a recognized laboratory. Consult your local AHJ before specifying.
⚡
Mains Voltage · No US Cert
This device operates with or switches mains voltage (120/240VAC) and
has not been certified by an NRTL. USA installation requires a Field
Evaluation by a recognized laboratory and explicit AHJ approval.
Regular price
$146.88 USD
Regular price
-20%
$183.60 USD
Sale price
$146.88 USD
Couldn't load pickup availability
KNX & DALI Specialists
Not sure which device fits your project? Our team speaks KNX. Contact us for a free technical recommendation.
Free shipping over $500
KNX certified devices
Expert technical support
Got questions?
Feel free to get in touch
Ask an expert!
The Lunatone DALI RM16 0-10V family converts DALI dim levels into 0-10V / 1-10V control signals with an integrated 16A relay — for larger ballast loads and, in the 2×0-10V versions, two independently controlled 0-10V outputs to run two power supplies (e.g. brightness + colour temperature) from one module. The relay cuts the ballast supply at dim value 0.
Key features
- DALI → 0-10V conversion with 16A relay
- Single-output DE version, Wieland-connector version, and dual 2×0-10V versions (DIN rail or DE)
- Configurable via DALI Cockpit
Versions
0-10V PWM DE (86458667-DE) · 1-10V PWM Wieland (86458936) · 2×0-10V DIN Rail (89453857-HS, 16A) · 2×0-10V DE (89453857-DE, 8A).
Technical specifications
| Output | 1–2 × 0-10V / 1-10V, current sink 1mA |
| Relay | 8–16A depending on version |
| Control | DALI |
