DALI-2 Touchpanel 04 PS
✗
UL Listed
This product has not been certified by an NRTL (UL, ETL, CSA or
equivalent). Installation in USA projects may require a Field Evaluation
by a recognized laboratory. Consult your local AHJ before specifying.
⚡
Mains Voltage · No US Cert
This device operates with or switches mains voltage (120/240VAC) and
has not been certified by an NRTL. USA installation requires a Field
Evaluation by a recognized laboratory and explicit AHJ approval.
Regular price
$361.44 USD
Regular price
-20%
$451.80 USD
Sale price
$361.44 USD
Couldn't load pickup availability
KNX & DALI Specialists
Not sure which device fits your project? Our team speaks KNX. Contact us for a free technical recommendation.
Free shipping over $500
KNX certified devices
Expert technical support
Got questions?
Feel free to get in touch
Ask an expert!
The Lunatone DALI-2 Touchpanel 04 PS is the flagship touch keypad with everything on board: glass touch surface with up to 16 configurable buttons, 4 status LEDs for the active group or scene, and an integrated mains-connected 70mA DALI bus power supply — the control interface and the DALI line's power source in one flush-mounted device.
Key features
- Integrated DALI PS 70mA powers the connected DALI line
- 4 LEDs visualise the active group / effective range / scene
- Up to 16 capacitive buttons configured in DALI Cockpit; selection-button layouts for groups and ranges
- Macros: colour temperature, dynamic scenes, sequences, user-defined command lists
- Interchangeable printed glass; extra glass sets and custom designs via configurator
- Multimaster, DALI-2 certified
Choose your layout
Six standard interfaces — clear glass, dimming with 4 groups, Tunable White or RGB with group/range selection buttons.
Technical specifications
| Supply | mains connection, integrated 70mA DALI PS |
| Mounting | on back box |
| Dimensions | 87.7 × 87.7 × 16.5 mm |
| Protection | IP40 housing / IP20 terminals |
| Operating temperature | -20°C to +45°C |
Panel plus bus power in a single box — the fastest route to a finished DALI room. Bus-powered version without PS: DALI-2 Touchpanel 04.
Orders over $500 ship free within the USA (under 50 lbs). Orders under $500 carry a low cost shipping fee.
Most in-stock orders ship within 1–2 business days from Miami, FL. Delivery typically takes 3–5 business days depending on destination.
For freight or oversized orders, our team will contact you with a custom quote.
All KNXSupply products are covered by the manufacturer's warranty, ranging from 1 to 3 years depending on the brand. Warranty terms are fulfilled directly by the manufacturer.
If you experience any issue, contact us and we'll coordinate the claim process on your behalf.
Buy in bulk
| Variant | Quantity | Price | Total |
|---|---|---|---|
|
Clear Glass (No Print)
24035290-PS-G000
|
|
||
|
DIM Buttons + 4 Groups + 4 Scenes
24035290-PS-G10A
|
|
||
|
DIM + Tunable White + 4 Group Selection + 4 Scenes
24035290-PS-G11A
|
|
||
|
DIM + Tunable White + 4 Range Selection + 4 Scenes
24035290-PS-G12A
|
|
||
|
DIM + RGB + 4 Group Selection + 4 Scenes
24035290-PS-G13A
|
|
||
|
DIM + RGB + 4 Range Selection + 4 Scenes
24035290-PS-G14A
|
|
