The SK80-WAQ is a KNX measuring unit for pool and technical water that reads pH and redox (ORP) electrodes and sends the values to the KNX bus. This version is supplied without electrodes, so standard combination pH/ORP probes can be fitted, and an optional PT1000 probe adds water temperature for compensation.

The surface-mount housing has a local LCD, two potential-free contact inputs and an IP54/65-rated bus coupler. It runs on KNX bus power alone.

Key Features

  • pH 0 to 13 and ORP/redox 0 to 2000 mV electrode inputs, galvanically isolated from KNX
  • Works with standard combination pH/ORP electrodes (3/4" x 16UNF / PG 13.5 thread) installed in a bypass line
  • Optional PT1000 input for water temperature 0 to +80 °C (32 to 176 °F) (±0.3 °C (±0.54 °F)) for compensation
  • 2 potential-free contact inputs (S1, S2); local LCD
  • Surface-mount housing; bus coupler IP54/65
  • Bus powered (approx. 10 mA); ETS application S8-WAQ

Technical Specifications

Article no. 30802100
KNX bus voltage KNX 21-32 VDC, bus load 10 mA
Power consumption approx. 10 mA from KNX bus
Auxiliary supply None stated (bus powered)
Measuring pH 0-13 (HI2114P electrode); ORP/redox 0-2000 mV (HI3214P electrode; ETS range -1200..+1200 mV); optional PT1000 water temperature 0..+80 °C (32 to 176 °F), accuracy ±0.3 °C (±0.54 °F); electrode input impedance >500 GOhm
Inputs / outputs & connections pH and ORP electrode inputs (galvanically isolated from KNX), optional PT1000 input for temperature compensation, 2 potential-free contact inputs (S1, S2); switching output not available as standard; local LCD
Protection rating IP54/65 (bus coupler)
Mounting Surface-mounted (AP) housing; probes installed in a bypass line, screwed in hand-tight (thread 3/4in x 16UNF / PG 13.5)
Operating temperature -25 to +60 °C (-13 to 140 °F) (storage -25 to +80 °C (-13 to 176 °F)), 0-100 % RH non-condensing; probes 0 to +80 °C (32 to 176 °F)

Application note: Supplied without electrodes; order the SK80-WAQ pH/ORP probe set separately or fit standard combination pH/ORP electrodes.
