KNX-IMPZ1-SK10 - KNX S0 Pulse Counter, 1 Channel, Surface Mount, IP54
KNX-IMPZ1-SK10 - KNX S0 Pulse Counter, 1 Channel, Surface Mount, IP54

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

ARCUS EDS

KNX-IMPZ1-SK10 - KNX S0 Pulse Counter, 1 Channel, Surface Mount, IP54

SKU: 60201101
(0)
✗ UL Listed
This product has not been certified by an NRTL (UL, ETL, CSA or equivalent). Installation in USA projects may require a Field Evaluation by a recognized laboratory. Consult your local AHJ before specifying.
~ Low Voltage · SELV
This device operates on a Safety Extra Low Voltage circuit — such as the KNX 29V bus or a DALI 16V bus (NEC Class 2). When powered by an NRTL-listed power supply, many AHJs accept non-listed SELV devices. Verify with your local AHJ before specifying.
$230.11 USD
-17% $276.14 USD $230.11 USD
In stock
On backorder
KNX & DALI Specialists

Not sure which device fits your project? Our team speaks KNX. Contact us for a free technical recommendation.

Free shipping over $500
KNX certified devices
Expert technical support

Got questions?

Feel free to get in touch

Ask an expert!

Video chat Chat Email +1 (786) 956-6821

The KNX-IMPZ1-SK10 is a single-channel impulse counter in a gray IP54 surface housing, designed to be mounted right next to the meter. It converts the S0 or pulse output of electricity, water or gas meters into KNX consumption values.

The counter runs on KNX bus power, needs no auxiliary supply and is configured in ETS with the IMPZx application. The housing mounts with two screws.

Key Features

  • 1 S0/pulse counter input
  • For electricity, water and gas meters with pulse outputs
  • Reports counts and consumption on KNX
  • Bus powered (approx. 240 mW), no auxiliary supply
  • IP54 gray surface housing, 72 x 64 x 40 mm (2.83 x 2.52 x 1.57 in), 2-screw mounting
  • ETS application IMPZx; operating range -20 to +55 °C (-4 to 131 °F)

Technical Specifications

Article no. 60201101
KNX bus voltage KNX 21-32 VDC
Power consumption approx. 240 mW at 24 VDC (bus powered)
Auxiliary supply Not required (bus coupler integrated)
Measuring 1 S0/impulse counter input
Inputs / outputs & connections KNX 2-pole terminal (red/black); 1 impulse (S0) input
Protection rating IP54
Dimensions 72 x 64 x 40 mm (2.83 x 2.52 x 1.57 in)
Mounting Surface mount, 2 screws, grey plastic
Operating temperature -20 to +55 °C (-4 to 131 °F) (storage -20 to +85 °C (-4 to 185 °F))

Downloads

(CE certified; not UL/NRTL listed — verify local code requirements before specifying in US installations)
