The KNX-GW2-RS485-2TE translates KNX telegrams into RS485 serial commands and back, for integrating AV equipment, projectors and other serially controlled devices. Around 1,200 serial commands can be stored in the gateway.

This slim 2-module DIN-rail version has an RS485 port only (no RS232) plus USB. Data formats and commands are set with the arcus KNX-SERIAL-GW-II PC tool rather than ETS. A 9-30 VDC auxiliary supply or USB power is required.

Key Features

  • Bidirectional KNX to RS485 gateway
  • Approx. 1,200 serial commands storable
  • RS485 only: galvanically isolated, 3 screw terminals, 120 Ω termination by jumper
  • USB port; configured with the KNX-SERIAL-GW-II PC tool
  • KNX galvanically separated from the serial side
  • Auxiliary supply 9-30 VDC, 100 mA (isolated, polarity-safe) or USB
  • 2-module DIN rail, IP20, -5 to +45 °C (23 to 113 °F)

Technical Specifications

Article no. 40210182
KNX bus voltage KNX 20-32 VDC (approx. 150 mW)
Power consumption approx. 150 mW from KNX; aux 9-30 VDC up to 100 mA
Auxiliary supply 9-30 VDC, 100 mA, internally galvanically isolated, polarity-safe – or USB
Inputs / outputs & connections KNX terminal; RS485 only (250 kBaud, galvanically isolated, 3 x screw terminals 0.8 mm2 (approx. 18 AWG), 120 Ohm termination by jumper); USB Type B per datasheet; 3 x 16-step rotary switch, T1, PRG + LED
Protection rating IP20
Mounting DIN rail, 2 TE (modules)
Operating temperature -5 to +45 °C (23 to 113 °F)
